2026 Review: Narwal Freo Z10 Ultra
18,000 Pa, LiDAR 4.0 and EdgeReach
All the facts on the Narwal Freo Z10 Ultra – from binocular AI and 75 °C mop washing to a comparison with MOVA, Dreame, ECOVACS and Roborock.
Quick verdict
The Narwal Freo Z10 Ultra is a robot vacuum and mop with 18,000 Pa suction, LiDAR 4.0 navigation and binocular AI (NarMind™ Pro). Two rotating Reuleaux mop pads extend into corners via the EdgeReach™ arm, while the all-in-one base handles emptying, washing and drying.
- 18,000 Pa suction, up to 99 % particle pick-up on hard floors
- LiDAR 4.0 with a 3D map across four levels and precise route planning
- Binocular AI: 200+ objects, 5 mm accuracy, 150 mm distance from pets
- Two rotating Reuleaux mops with EdgeReach™ – right into 0 mm corners and edges
- All-in-one base: auto-empty up to 120 days, 75 °C mop wash, hot-air drying
- DualFlow anti-tangle system – ideal for pets and long hair
- Very quiet (under 55 dB) and connected via Alexa, Google, Siri and the app
Narwal Freo Z10 Ultra
Robot vacuum and mop with 18,000 Pa suction, LiDAR 4.0 navigation, binocular AI (200+ objects) and two rotating Reuleaux mop pads that extend via the EdgeReach™ arm into 0 mm corners. The all-in-one base washes the mops with water up to 75 °C, dries them with hot air and empties the dust automatically for up to 120 days.
approx. €549–599Street price depending on retailer & deal (RRP €1,299)
Pros
- 18,000 Pa suction with up to 99 % particle pick-up on hard floors
- Rotating Reuleaux twin mops with EdgeReach™ arm – right into 0 mm corners and edges
- Binocular AI (NarMind™ Pro): 200+ objects, 5 mm accuracy, 150 mm distance from pets
- SGS-certified DualFlow anti-tangle system – ideal for pet and long hair
Cons
- Mop only lifts 12 mm – it can leave streaks on thick or high-pile carpets
- No adjustable mop pressure: fixed 8 N contact pressure
- 2.4 GHz Wi-Fi only – no 5 GHz network
- No Matter/HomeKit; smart home runs via Alexa, Google and Siri
What is the Narwal Freo Z10 Ultra?
The Narwal Freo Z10 Ultra is the current flagship of the Freo line and a robot vacuum and mop with a fully automatic all-in-one base. Instead of a single mop roller, Narwal uses two rotating Reuleaux-triangle mop pads whose extendable EdgeReach™ arm reaches into 0 mm gaps along edges and corners. Powering it is 18,000 Pa of suction and the NarMind™ Pro autonomous system: two 136° RGB cameras and two AI chips (4 TOPS) detect over 200 object types to 5 mm accuracy according to the manufacturer – cables, shoes or toys are reliably avoided, and the robot keeps a 150 mm distance from pets. This is the device's core claim: it decides in real time whether to vacuum or mop, raises the mop by 12 mm on carpets, boosts suction there by 160 % and cleans wet and dry mess with separate systems. Maintenance is minimal: the base empties the robot's bin into a 2.5 litre dust bag (up to 120 days), doses detergent itself and washes the mops with water up to 75 °C before drying them with hot air. The 6,400 mAh battery runs for around 120 minutes of combined vacuum-and-mop or up to 200 minutes of mopping only. That makes the Freo Z10 Ultra especially interesting for homes with pets or long hair – the SGS-certified DualFlow anti-tangle system keeps the brush and roller largely free.
The Freo Z10 Ultra is the current flagship of Narwal's Freo Z10 line. Narwal became known above all for its self-cleaning mop pads, and in this model it combines very strong suction with the new EdgeReach™ mop module for the first time: an extendable arm that pushes the rotating Reuleaux mops into the very last corner. If you search for "Narwal Freo" you will also come across the Freo Z Ultra, Freo Z10 Pro and Freo 20 – they differ in suction, mopping system and price. The Freo Z10 Ultra is currently the strongest all-round solution for homes with hard floors and carpet.
Also worth a look: our other robot vacuum reviews
Comparing several models? We have reviewed more robot vacuums in depth – from the affordable ECOVACS DEEBOT T80 OMNI to the 30,000 Pa powerhouse MOVA P70 Pro Ultra. Worth checking if price or suction matters more to you than the mopping system.
18,000 Pa, LiDAR 4.0 & binocular AI
How the Narwal Freo Z10 Ultra works at home – autonomously, thoroughly and app-connected.
18,000 Pa suction
The dynamic turbo suction removes up to 99.43 % of all dust particles according to the manufacturer. The V-shaped DualFlow design feeds hair straight into the dust bin.
LiDAR 4.0 & 3D map
A 360° laser scanner instantly builds a detailed 3D map across up to four levels and plans the most efficient cleaning route from it.
Binocular AI (NarMind™ Pro)
Two 136° cameras and two AI chips (4 TOPS) recognise over 200 object types to 5 mm accuracy – including a safety distance from pets.
All-in-one base
Auto-empty up to 120 days via the 2.5 litre bag, automatic detergent dosing, adaptive mop washing up to 75 °C and hot-air drying.
Everyday use: setup, mopping, edges
Set up in minutes
Place the all-in-one base, fill the clean water tank, connect the robot to your 2.4 GHz Wi-Fi via the Narwal app and let it map your home. The first run builds a 3D map across up to four levels; afterwards you assign rooms and no-go zones. From unboxing to the first full clean, expect roughly half an hour to an hour.
Vacuum and mop in one pass
The Freo Z10 Ultra decides in real time whether to vacuum or mop: the AI detects wet and dry dirt and adapts its strategy. With 18,000 Pa it picks up crumbs, sand and pet hair while the two rotating mops follow with 8 N of contact pressure. On hard floors it reaches up to 99 % particle pick-up according to the manufacturer, and on carpet it raises the mops by 12 mm and boosts suction by 160 %.
Edges and corners – the EdgeReach advantage
Unlike pure mop rollers, the Reuleaux triangle mop module extends on an arm and mops into 0 mm gaps along walls, skirting boards and furniture feet. EdgeSwing technology maintains contact pressure – the spot where you would otherwise wipe by hand is actively cleaned.
Maintenance: almost automatic
After every run the base empties the robot's bin into a 2.5 litre bag (up to 120 days), doses detergent itself and washes the mops with water up to 75 °C before drying them with hot air. You refill or empty the clean and dirty water tanks (4.5 l / 4.05 l) roughly weekly – there is little else to do.
Noise
When mopping the robot stays below 56 dB and below 59 dB when vacuuming – pleasantly quiet for a robot vacuum with an auto-empty base, so it barely disturbs everyday life.
Technical specs: Narwal Freo Z10 Ultra
All values per the official Narwal product page; deviations are marked.
| Type | Robot vacuum and mop with all-in-one auto-empty base |
| Suction power | 18.000 Pa |
| Navigation | LiDAR 4.0 (360° scan, 3D map across four levels, gyroscope & compass) combined with the NarMind™ Pro binocular AI system (two 136° RGB cameras and two AI chips with 4 TOPS) |
| Obstacle detection | NarMind™ Pro with binocular cameras: over 200 object types, 5 mm measuring accuracy, 8 mm edge guidance and 150 mm safety distance from pets |
| Mopping system | Two rotating Reuleaux-triangle mop pads with an extendable EdgeReach™ arm (Lelo shape, 10 mm overlap) |
| Contact pressure | 8 N |
| Mop lift (carpet) | 12 mm |
| Carpet cleaning | Automatic carpet detection: raises the mop by 12 mm and boosts suction by 160 % on carpet |
| Edge/corner cleaning | EdgeReach™ extendable arm plus EdgeSwing: mops right into 0 mm gaps along edges and corners |
| Anti-tangle | DualFlow anti-tangle system (V-shaped side brushes + floating main roller), SGS-certified |
| Mop washing (base) | Adaptive hot-water mop washing from 45 to 75 °C, including a 75 °C hot-water rinse |
| Mop drying | Hot-air drying (approx. 40 °C) with electrolytic water sterilisation (up to 99.99 % bacteria reduction) |
| Dust bag (base) | 2,5 l, up to 120 days |
| Clean/dirty water | 4,5 l / 4,05 l |
| Battery | 6.400 mAh (72 Wh) |
| Runtime | 120 min (vacuum + mop) / 200 min (mop only) |
| Cleaning area | up to 120 m² (vacuum + mop) or 200 m² (mop only) per charge |
| Noise level | under 55 dB(A) (mopping ≤ 56 dB, vacuuming ≤ 59 dB) |
| Climbing ability (threshold) | up to 20 mm |
| Connectivity | 2.4 GHz Wi-Fi and Bluetooth |
| App control | Yes, Narwal app (iOS/Android) with live video, no-go zones, cleaning schedules and pet mode |
| Smart home | Amazon Alexa, Google Home and Apple Siri; built-in HeyNawa voice assistant with more than 30 commands |
| Protection | IP52 (robot and base) |
| Robot weight | 4,5 kg |
| Robot dimensions | 355 × 350 × 109.6 mm |
| Base weight | 12,2 kg |
| Base dimensions | 430.8 × 388.3 × 462 mm |
| Availability | on sale since 2026; sold in Germany via de.narwal.com, Amazon.de, Bauhaus, Otto and others |
| Price (RRP) | €1,299.00 (RRP, de.narwal.com) |
| Price (current lowest) | de.narwal.com from €599.00 (RRP €1,299, about €700 off); Amazon.de approx. €599 |
Sources: de.narwal.com (official product page), amazon.de, bauhaus.info and otto.de (manufacturer data on dimensions and noise).
Pros & cons at a glance
Pros
- 18,000 Pa suction with up to 99 % particle pick-up on hard floors
- Rotating Reuleaux twin mops with EdgeReach™ arm – right into 0 mm corners and edges
- Binocular AI (NarMind™ Pro): 200+ objects, 5 mm accuracy, 150 mm distance from pets
- SGS-certified DualFlow anti-tangle system – ideal for pet and long hair
- All-in-one base: auto-empty up to 120 days, detergent dosing, 75 °C mop wash and hot-air drying
- Very quiet (under 55 dB) thanks to the ultra-quiet base
- LiDAR 4.0 with a 3D map across four levels and clean route planning
- App with live video, no-go zones and pet mode; Alexa, Google Home and Siri
Cons
- Mop only lifts 12 mm – it can leave streaks on thick or high-pile carpets
- No adjustable mop pressure: fixed 8 N contact pressure
- 2.4 GHz Wi-Fi only – no 5 GHz network
- No Matter/HomeKit; smart home runs via Alexa, Google and Siri
- Spare parts and detergent are tied to Narwal accessories (ongoing cost)
- Even on offer, clearly pricier than entry models such as the ECOVACS DEEBOT T80 OMNI
- App handling and map accuracy are sometimes described as improvable in user reports
Freo Z10 Ultra vs. Freo Z Ultra and Freo 20
Narwal's line-up differs mainly in suction, mopping system and price.
| Model | Suction | Mopping system | AI/obstacles | Price approx. |
|---|---|---|---|---|
| Freo Z10 Ultra (tested) | 18,000 Pa | 2 rotating Reuleaux mops + EdgeReach | Binocular AI, 200+ objects | approx. €599 |
| Freo Z Ultra | 12,000 Pa | 2 rotating mops | AI camera, dual chip | sold out / EOL |
| Freo Z10 Pro | 18,000 Pa | 2 rotating mops (carpet focus) | AI camera | approx. €449–549 |
| Freo 20 | 31,000 Pa | FlowWash mop roller, 100 °C | TwinAI obstacle avoidance | approx. €899–999 |
Source: de.narwal.com (Freo range overview) and manufacturer data, as of 2026. The Freo Z Ultra is no longer actively sold by Narwal and is largely out of stock.
Narwal Freo Z10 Ultra vs. the competition
How does the Freo Z10 Ultra compare with MOVA, Dreame, ECOVACS and Roborock – models we have also reviewed?
| Model | Suction | Navigation/AI | Mopping system | Price approx. |
|---|---|---|---|---|
| Narwal Freo Z10 Ultra | 18,000 Pa | LiDAR 4.0 + binocular AI | 2 rotating mops + EdgeReach | approx. €599 |
| MOVA P70 Pro Ultra | 30,000 Pa | LDS LiDAR + AI (280 objects) | 2 rotating pads, 12 N | approx. €487–549 |
| Dreame L50s Pro Ultra | 30,000 Pa | LiDAR + AI | 2 rotating pads | approx. €599–659 |
| MOVA P50 Pro Ultra | 19,000 Pa | LiDAR + AI | 2 rotating pads | approx. €429–472 |
| ECOVACS DEEBOT T80 OMNI | 18,000 Pa | dToF + AIVI 3D 3.0 | OZMO roller mop | approx. €349–384 |
| Roborock Qrevo Curv | 18,500 Pa | LiDAR + AI | 2 rotating pads | approx. €768–899 |
Sources: manufacturer data from each brand and our own reviews (as of 2026). Prices are guide values and vary with promotions.
On pure suction, the MOVA P70 Pro Ultra and Dreame L50s Pro Ultra lead with 30,000 Pa – the strongest vacuums for very pet- and dirt-heavy homes. The Freo Z10 Ultra scores with its mopping system: the extendable Reuleaux mops with EdgeReach clean corners and edges far more actively than classic pad robots, and the all-in-one base washes at up to 75 °C. If you want the cheapest overall package, the ECOVACS DEEBOT T80 OMNI from around €350 is the best pick (though with less suction and a mop roller instead of twin pads). The Roborock Qrevo Curv is solid but expensive in comparison. For homes with pets and lots of hard floor, the Freo Z10 Ultra is one of the most balanced options; if you need maximum suction, the MOVA P70 Pro Ultra deserves a place on your shortlist.
Problems, notes & tips from Narwal owners
What we most often encounter in forums and user reports about the Freo Z10 Ultra.
1. 2.4 GHz Wi-Fi is essential
The most common setup hurdle: the robot only connects to a 2.4 GHz network. On modern routers using a single SSID for 2.4 and 5 GHz, pairing sometimes fails. Tip: enable a separate 2.4 GHz network on your router and register the robot there.
2. Carpets: mind the mop lift
The mop only lifts 12 mm. On flat rugs and runners this works reliably, but on high-pile or very dense carpet the mop may drag and release moisture. Users recommend excluding such rugs with a no-go zone or starting the mop wash only after carpet cleaning.
3. Fine-tune map accuracy
Automatic mapping is good but keeps some distance at certain edges. You can redraw the map with your finger in the app – especially worthwhile for awkward floor plans so the robot drives right up to the skirting board next time.
4. Detergent and spare parts
The base doses floor detergent automatically but works best with Narwal's own solution. Refills, dust bags and mops are tied to Narwal accessories – factor in these ongoing costs when buying.
5. Live video and privacy
The Freo Z10 Ultra can stream live video from its cameras via the app. If you don't want that, you can disable the feature in the app settings – obstacle detection keeps working.
Who is the Narwal Freo Z10 Ultra for?
Households with plenty of hard floor, some carpet and above all pets or long hair, looking for a device that reliably combines vacuuming and mopping, actively mops corners and largely takes care of maintenance itself – and who are ready to spend around €550–600.
Price & availability
The Narwal Freo Z10 Ultra is available via Amazon, the official Narwal shop and electrical retailers.
| Retailer | Region | Price |
|---|---|---|
| Amazon.de | Germany | approx. €599.00 |
| de.narwal.com (manufacturer shop) | Germany | €599.00 instead of €1,299.00 (RRP) |
| Bauhaus / Otto (retail) | Germany | approx. €599–699 depending on the deal |
| Accessory bundles (Narwal) | Germany | €619 with basic kit, €699 with 1-year, €799 with 2-year accessory kit |
Price research as of October 2026. Prices can change at any time – see the current terms via the buttons below. Sources: amazon.de, de.narwal.com, bauhaus.info, otto.de.
FAQ about the Narwal Freo Z10 Ultra
Our verdict
The Narwal Freo Z10 Ultra is a very mature robot vacuum and mop for homes with plenty of hard floor, some carpet and pets. Its strengths are the active mopping system with extendable Reuleaux mops and EdgeReach, the strong 18,000 Pa suction and the all-in-one base that handles emptying, washing up to 75 °C and hot-air drying. The SGS-certified anti-tangle system and the binocular AI with over 200 recognised objects make everyday use pleasantly simple. Points of criticism are the comparatively low 12 mm mop lift, the 2.4 GHz Wi-Fi limitation and the Narwal-bound accessories. If you can live with that and want corners genuinely clean, you get one of the most interesting robot vacuums in its class for around €550–600.
Sources
- de.narwal.com – official Narwal Freo Z10 Ultra product page
- amazon.de – Narwal Freo Z10 Ultra (product details and customer reviews)
- bauhaus.info – Narwal Freo Z10 Ultra (technical data)
- otto.de – Narwal Freo Z10 Ultra (manufacturer data)
- Our own reviews of the MOVA P70 Pro Ultra, Dreame L50s Pro Ultra, ECOVACS DEEBOT T80 OMNI and Roborock Qrevo Curv (daschmi.de/af)
As of: October 2026.
